Premium Conventional Safety Valve supplied by African Valve for industrial flow control. We stock comprehensive specifications in multiple materials and sizes, available across Africa with expert technical support and fast delivery.
Product Overview
Pressure Rating
Set Pressure Range: 15-6000 PSI (1-414 bar). Overpressure: 10% accumulation maximum. Back pressure: Up to 10% of set pressure conventional design
Temperature Range
Service Temperature: -29°C to 454°C (-20°F to 850°F) for carbon steel. Stainless steel extends range to 538°C (1000°F). Steam and gas service
Material Construction
Body: Carbon steel ASTM A216 WCB or stainless steel 316 CF8M
Spring: Chrome silicon alloy steel per ASTM A401
Disc: 316 stainless steel with hard-faced seating surface
Seat Ring: Stellite 6 hard-faced renewable
Bonnet: Carbon steel or stainless steel bolted
Adjustment: External screw with lock nut
Connection Type
Flanged (ANSI B16.5), Threaded (NPT/BSP)
Looking for more details?
View complete technical specifications in the Specifications tab, check out Features and Applications, or download product documentation from the Downloads tab.
$159.99
