Pneumatic Actuated Two Piece Ball Valve
Pneumatic Actuated Two Piece Ball Valve ensures automated on/off control with reliable shutoff and smooth flow for industrial use across Africa.
Starting at$99.99
Contact Us
1 / 2
Product Overview
Pressure Rating
Working Pressure: ANSI Class 150-800 (PN16-PN140): Class 150 (275 PSI), Class 300 (720 PSI), Class 800 (1440 PSI threaded). Electric actuator: 24-480V AC/DC, torque output 50-2000 Nm
Temperature Range
Operating Temperature: -40°C to 200°C (-40°F to 392°F) with PTFE seats. Metal seat option extends range to 454°C (850°F). Electric actuator: -40°C to 80°C ambient
Material Construction
Body: Carbon steel ASTM A216 WCB with 2-piece threaded construction
Ball: 316 stainless steel with precision lapped surfaces
Stem: 17-4PH stainless steel with anti-blowout design
Seats: PTFE with spring energizer
Actuator: Electric motor with gear reduction and position indication
Connections: NPT threaded with anti-seize compound
Connection Type
Flanged (ANSI B16.5), Threaded (NPT/BSP)
Looking for more details?
View complete technical specifications in the Specifications tab, check out Features and Applications, or download product documentation from the Downloads tab.
